| Product Type | Custom Configured |
| HCPCS Code | Seat: E2609 Back: E2617 |
| Available Width Range | 6" and up |
| Available Depth Range | All dimensions available pending manufacturing approval |
| Available Height Range | All dimensions available pending manufacturing approval |
| Product Weight | Depends on Configuration |
| Weight Capacity | Non-Transit: 250 lbs. Non-Transit HD: 300 lbs. Transit: Minimum 48 lbs. - Maximum 200 lbs. |
| Transit Approved Hardware | Yes |
| Options and Accessories | |
| Seat Contour | Flat Wedge Anti-Thrust Quick Fit Adjustable Anti-Thrust Contoured Seat Quick Fit Adjustable Contoured Seat |
| Seat Base | Standard ABS Custom Heavy Duty PlasticTech |
| Seat Foam Insert | Sunmate Visco Pudgee High Resiliency |
| Seat Attachment Hardware | Universal (Transit) Universal Adjustable Drop Hook Style Fixed Drop Hook Style EZ Mount Snap-on |
| Seat Contact Surface Fabric | Rubatex Naugahyde Dartex Reverse Dartex |
| Seat Non-Contact Surface Fabric | Rubatex Naugahyde Dartex Reverse Dartex |
| Anterior Pelvic Supports | Single, Dual or 4-Point push button or plastic side release |
| Lateral Pelvic Supports | Custom Pelvic/Thigh Pad Contoured Pelvic/Thigh Pad 3" x 4" Pelvic Pad 4" x 5" Pelvic Pad 4" x 6" Pelvic Pad 5" x 6" Pelvic Pad |
| Lateral Adductor Supports | 3" x 4" Adductor Pad 4" x 4" Adductor Pad 4" x 5" Adductor Pad 3" Round Adductor Pad 4" Round Adductor Pad |
| Medial Thigh Support | Oval Wedge |
| Lower Extremity Supports | ABS Shoe Holder Tendon Relief Shoe Holder Foot and Ankle Positioner Angle Positioner |
| Back Contour | Flat Curved by Foam Contoured Quick Fit Contour Bi-Angular Foam Form |
| Back Base | Standard ABS Custom Heavy Duty PlasticTech Curved Curved PlastiTech |
| Back Foam Insert | Sunmate Visco Pudgee High Resiliency |
| Back Attachment Hardware | Universal (Transit) Universal Adjustable Drop Hook Style Fixed Drop Hook Style EZ Mount Snap-on |
| Back Contact Surface Fabric | Rubatex Naugahyde Dartex Reverse Dartex |
| Back Non-Contact Surface Fabric | Rubatex Naugahyde Dartex Reverse Dartex |
| Lateral Thoracic Supports | Available in Curved D, Flat D, Flat Tapered: 3" x 3" 3" x 5" 3.5" x 4" 4" x 5" 4.5" x 5.5" 5" x 6" 5.5" x 6" |
| Anterior Thoracic Supports | Classic ComforFit Contour ComforFit Center Opening ComforFit Zippie Open ComforFit Butterfly Vest Anterior Trunk Strap |
| Protractor Supports | 3" x 3" 3" x 4" 4" x 5" 4" x 6" |
| Retractor Supports | Structured Backpack Style Shoulder Straps Dynamic Backpack Style Shoulder Straps Y-Style Structured Y-Style Dynamic |
| Upper Extremity Supports | Arm Troughs Wood Tray Polycarbonate Tray 1/4" Polycarbonate Tray |
| Head Supports | Plush C-Plush Dual Plush Narrow Plush Contoured Cradle Occipital Pad Adjust-A-Plush Flat Head Support Panel T-Bar Pad Single Sub Occipital Dual Sub Occipital DFS Squared Dynamic Forehead Strap Strap Cap Hedz-Up |
