| Model Number | EIX2 |
| Starting Retail Price | $2,930 |
| Frame Style | Folding |
| HCPCS Code | K0005 |
| Wheelchair Weight | Fixed Front: as low as 19.4 lbs (14.4 lbs transport weight) Hybrid: as low as 20.9 lbs (16 lbs transport weight) Swing-Away: as low as 22.7 lbs (17.7 lbs transport weight) Weights based on common size (16" x 16") and can vary based on wheelchair configuration and material tolerances. Weights subject to change without notice. |
| Frame Material | 7000 Series Aluminum |
| User Weight Capacity | Fixed Front: 240 lbs Hybrid: 300 lbs Swing-Away: 265 lbs |
| Transit Approved | No |
| Shipping Dimensions | 31" L x 24" H x 24" W |
| Average Shipping Weight | 50 lbs. |
| Frame and Feature Measurements | |
| Seat Widths | Fixed Front: 12.5" to 18" (32 to 46 cm) Hybrid: 12.5" to 19.5" (32 to 50 cm) Swing-Away: 12.5" to 19.5" (32 to 50 cm) |
| Seat Depths | Fixed Front: 13.5" to 19.5" (34.3 to 50 cm) Hybrid: 13.5" to 19.5" (34.3 to 50 cm) Swing-Away: 13.5" to 19.5" (34.3 to 50 cm) |
| Frame Angle | 80°, 88° |
| Front Seat-to-Floor Height | Fixed Front: 17" to 21.5" (43 to 55 cm) Hybrid: 17" to 21.5" (43 to 55 cm) Swing-Away: 17" to 22" (43 to 56 cm) |
| Rear Seat-to-Floor Height | Fixed Front: 14.5" to 19.5" (37 to 50 cm) Hybrid: 14.5" to 19.5" (37 to 50 cm) Swing-Away: 14.5" to 19.5" (37 to 50 cm) |
| Lower Leg Length Setting | 8.6" to 17.7" (22 to 45 cm) |
| Back Height | 9.8" to 18.7" (25 to 47.5 cm) |
| Angle Adjustable Backrest Adjustment Range | Fore (-) 15° to Aft (+) 13° |
| Camber | 0° / 2° / 4° |
| Center of Gravity (COG) Adjustment | 0.5" to 4.0" (1 to 10 cm) |
| Tilt Range | N/A |
| Options and Accessories | |
| Frame Type | Fixed Front Hybrid Swing-Away |
| Special Packages | Carbon Package: Proton Rear Wheel Carbon Platform footplate / Leg strap Carbon side guard w/ Large fender Ultra Lite Package: Proton Rear Wheel Schwalbe Speed Run Tire Compact Wheel Lock |
| Tilt Release Options | N/A |
| Frame Inset | 0 or 1 cm |
| Caster Wheels | 3" Micro 4" Low Profile Polyurethane 4" Micro Lighted 4" x 1" Aluminum Polyurethane 4" x 1.25" Semi Pneumatic 4" x 1.5" Aluminum Soft Roll 5" Low Profile Polyurethane 5" Micro Lighted 5" x 1" Aluminum Polyurethane 5" x 1.5" Semi-Pneumatic 5" Soft Roll (Grey) 5" x 1.5" Aluminum Soft Roll 6" Polyurethane 6" Pneumatic 6" x 1.5" Semi Pneumatic 6" x 1.5" Aluminum Soft Roll |
| Caster Options | Multi-Position Single Sided Frog Legs |
| Hangers | 70°, 80°, ELR |
| Footplates | Composites (divided) Composites Angle Adj (divided) Aluminum Angle Adj (divided) Multi-Angle Adj (Zfinity) Platform Composite Platform Aluminum Ultra Lite Platform Platform Carbon Fiber |
| Footplate Options | Heel Loops Leg Strap Gel Hanger Cover Position Plates Platform Swing-Away Mechanism |
| Axle | Quick Release Steel Quad Quick Release |
| Axle Plate | Adjustable COG |
| Rear Wheel Type | 24" Mag Wheel 5-Spoke 24" Lite Spoke Wheel 25" Lite Spoke Wheel 24" Ultra Lightweight Spoke Wheel 25" Ultra Lightweight Spoke Wheel 24" Spinergy SPOX Black 25" Spinergy SPOX Black 24" Spinergy LX Black 25" Spinergy LX Black 24" Mountain 24" Proton Wheel 25" Proton Wheel 24" Drum Brake Wheel - 36 Spokes |
| Rear Wheel Tire | Pneumatic Pneumatic with Airless Insert Full Poly SHOX Performance Poly High-Pressure Clincher Black Knobby V-TRAK Schwalbe® Marathon Plus Evolution Schwalbe® Speed Run Schwalbe® Down Town Two Grip Schwalbe® Right Run Mountain Tire |
| Handrims | Aluminum Anodized Aluminum Powder Coated Colored Plastic Coated Natural Fit - Standard Grip Natural Fit - Super Grip Natural Fit - No Thumb Grip Natural Fit LT - Standard Grip Natural Fit LT - Super Grip Natural Fit LT - No Thumb Grip The Surge - Oval w/ Gription Strip The Surge LT - Oval w/ Gription Strip Q-Grip Neoprene Coated Spinergy Flex Rim |
| Hub Lock | N/A |
| Suspension | Frog Legs Caster Suspension |
| Backrest Type | Fixed Fixed Fold Down (to the front) Angle Adjustable Back (75° - 103°) |
| Back Post Options | Push Handle Ergo Grip Long Fold Down Push Handles Height Adjustable Push Handles |
| Backrest Options | Stabilizer Bar Stabilizer Bar Swing-Away |
| Back Upholstery | Standard EXO Tension Adjustable EXO Tension Adjustable EXO Pro 3DX J3 JAY Back |
| Military Service Patches | Marines Army Navy Air Force Coast Guard Purple Heart |
| Armrests | Padded Swing-Away Fixed Padded Swing-Away Height Adj Single Post Height Adjustable Removable Desk Sideguard Flip Up Fixed Desk Sideguard Flip Up Height Adj |
| Arm Pads | Desk Length |
| Wheel Locks | Direct Mount High Mount Push High Mount Pull Ergo Scissor Compact 6" Extension Handle Pair |
| Seating | Tension Adj Seat Sling No Pocket Tension Adj Seat Sling 1 Utility Bag 2" Cushion JAY Cushions |
| Power Assist | N/A |
| Grade Aid | N/A |
| Anti-Tips | Rear Anti-Tips Anti-Tip Swing-Away Tip Assist |
| Side Guards | Plastic - Standard Plastic - Low Aluminum Aluminum with Fender Carbon Fiber Carbon Fiber with Fender |
| Side Guard Options | Frame color match for Aluminum or Aluminum with Fender |
| Positioning Belts | Universal 1.5" Auto Buckle Belt |
| Tray Tables | Small Medium Large X-Large |
| Accessories | Quickie Backpack Zippie Backpack Seat Pouch Caddy Clear Spoke Guard Black Spoke Guard Gel Cover Hanger/Frame Gel Swing-Away Pad Extra Leg Strap Black Crutch Holder Tool Kit Mobile Phone Pocket Lower Extremity Swing-Away Support |
| Frame Color Options | Aztec Gold Bead Blast Black Black Cherry Black Opal Blue Opal Candy Blue Candy Purple Candy Red Electric Blue Evergreen Glossy White Glow Green Apple Hot Sparkle Pink Mauve Pink Rootbeer Sparkle Silver Sunrise Orange Titanium Color Paint Yellow Matte Black Matte Black Cherry Matte Electric Blue Matte Evergreen Matte Purple |
| Anodized Color Options | Black Blue Gold Lime Green Purple Red Ti Grey |
